- Place of Origin:ZHUZHOU,CHINA
- Brand Name:OEM
- Model Number:8.5X3.5X2.5 and others
- Alloy Specification:K01 K05 K10 K20
- Particle:Fine Grain
Grades recommended for Copper, Aluminium
Density | Hardness | T.R.S* | Recommended cutting applications | ISO Standard | |
g/cm3 | HRA | N/mm2(MPa) | |||
Micron and sub-micron grain grade | |||||
SM05 | 15.0-15.2 | 94.3 | ≥2500 | 16"-18"high-quality Saw blade for bridge-cut aluminum and aluminium door, window etc | K01 |
SM06 | 14.9-15.1 | 94.0 | ≥2600 | 16"-18"high & medium quality Saw blade for bridge-cut aluminum and aluminium door, window etc | K05 |
SM07 | 14.8-15.0 | 93.7 | ≥2700 | 8"-14"high & medium quality Saw blade for copper and aluminum etc | K05 |
SM09 | 14.7-14.9 | 93.0 | ≥2700 | 8"high quality Saw blade for copper and aluminum; 8"-14"high & medium quality Saw blade for aluminium bar & aluminium extrustion profile | K05 |
XK20 | 14.6-14.8 | 90.0 | >2500 | 7"-10"Economical Saw blade for aluminum,copper etc | K20 |
Inner Package: Solid plastic bottle for 1kg, 3 kg as your requirement.
Outter package: Standard paper carton or solid iron bucket as your will
Overview of our workshop
Experienced workers who can operate 4 automatic pressing machine at the same time, they are working here since the built of Xinpin;
Advanced sintering furnance, 300kg carbide products can be sintered together for everyday, we have 3 sintered furnances for different products ( Medium grain, micron and sub-micron grain, different grain require their own adoptable sintering process to get the stable performance items )
Advanced Hot-isostatic sintering furnace : 24 hours HIP sintering, under can effectuvekt eliminate the internal porosity of the allo and significantly improve the bending strength of the products, especial for the carbide strips.
